0-20m Level Sensor 20m Cable 4-20mA Output Level Sensor Transmitter(20m Cable 0-10V)

Vibration SensorsThis product link price is for parameters:1. Level range 0-100m. (optional)2. Cable length 100m(optional)3. Output signal 4-20mA (0-10v rs485 etc are available. contact our sales for more info please.)4. Power supply: 24vdc HDL300 serieswater leveltransmitter pressure sensitive core adopts high performance silicon piezoresistive pressure filling core. The internal converts the sensor millivolt signal into standard voltage current or frequency signal which can be directly connected with computer interface card control instrument intelligent instrument or PLC. Current output mode can be used for distance transmission. The product is easy to install and has high anti-vibration and anti-impact performance. It is widely used in process control aviation aerospace automobile HVAC and other fields.Product name4-20mA output water level transmitter sensorRange 0..1...2...5...8...10...100mH2OOverload Pressure 200% ;Transmission Distance 1Km(supply 24V)Acc. 0.5%FS 0.25%FSLong-term StabilityTypical:±0.1%FS/yearTemperature effect on zeroTypical:±0.02%FS/ Max±0.05%FS/Sensitivity Temperature driftTypical:±0.02%FS/ Max±0.05%FS/Operating Temperature 0~80(Customized product to 100)Compensation Temperature 0~ 70Storage Temperature -40~100Electric ProtectionReverse connect protection Excess voltage protectionProtection Grade IP68Measurement Medium water oilPressure ConnectionInput Type; Mounted Type(G1/4 G1/2 M20*1.5 selectable)Shell Stainless SteelSupply 9-36VDC (Typical24V)Output Signal 4-20mAFeature:1 Prevent from the surge voltage over-voltage over-current and the protection of reversed polarity;2 Do the test to make sure the ability of overload resistance and shock resistance previously ensure the overload capacity;3 Implement the electromagnetic interference resistance to avoid the problem taken p

• Vibration Sensors
• 【Stable and Reliable】 The liquid level sensor is designed with precision compensation technology and the components are sensitive stable and reliable.
• 【Multiple Pressure Ranges】Multiple ranges are available for you to choose from sufficient to meet your purchasing needs.
• 【Easy to install and operate】The level sensor is lightweight small in size and easy to install and operate.
• 【Widely used】 Diesel oil underwater level sensor wastewater.suitable for a bad environment
